Page #74 background imageLoading...
Page #74 background image
4-16
X8DA3/X8DAi User’s Manual
Select Boot Loader to keep Console Redirection active during POST and Boot
Loader. The options are Disabled, Boot Loader, and Always.
Terminal Type
This feature allows the user to select the target terminal type for Console Redi-
rection. The options are ANSI, VT100, and VT-UTF8.
VT-UTF8 Combo Key Support
A terminal keyboard de nition that provides a way to send commands from a
remote console. Available options are Enabled and Disabled.
Sredir Memory Display Delay
This feature de nes the length of time in seconds to display memory information.
The options are No Delay, Delay 1 Sec, Delay 2 Sec, and Delay 4 Sec.
System Health Monitor
This feature allows the user to monitor system health and review the status of each
item as displayed.
CPU Overheat Alarm
This option allows the user to select the CPU Overheat Alarm setting which de-
termines when the CPU OH alarm will be activated to provide warning of possible
CPU overheat.
Warning!
1. Any temperature that exceeds the CPU threshold temperature pre-
de ned by the CPU manufacturer may result in CPU overheat or system
instability. When the CPU temperature reaches this prede ned threshold,
the CPU and system cooling fans will run at full speed.
2. To avoid possible system overheating, please be sure to provide ad-
equate air ow to your system.
The options are:
The Early Alarm: Select this setting if you want the CPU overheat alarm (includ-
ing the LED and the buzzer) to be triggered as soon as the CPU temperature
reaches the CPU overheat threshold as prede ned by the CPU manufacturer.
The Default Alarm
: Select this setting if you want the CPU overheat alarm
(including the LED and the buzzer) to be triggered when the CPU temperature
reaches about 5
o
C above the threshold temperature as prede ned by the CPU
manufacturer to give the CPU and system fans additional time needed for CPU
