Chapter 1: Introduction
1-7
Power-up mode control for recovery from AC power loss•
Auto-switching voltage regulator for CPU cores•
System overheat/Fan Fail LED Indicator and control•
Chassis intrusion detection•
System resource alert via Supero Doctor III•
ACPI Features
Slow blinking LED for suspend state indicator•
Main switch override mechanism•
ACPI Power Management•
Keyboard Wakeup from Soft-off •
Onboard I/O
Intel ICH10R supports six SATA2 ports (with RAID0, RAID1, RAID10, RAID5 •
supported in the Windows OS Environment)
LSI 1068E supports eight SAS ports (with RAID0, RAID1, RAID10 supported)
•
(For X8DA3)
Note: SAS RAID5 is also supported when the AOC-Ibutton 68 (optional)
is installed on the motherboard.
One SIMLC IPMI socket
•
Intel 82573V and 82573L Gigabit Ethernet controllers support dual Giga-bit •
LAN ports
One fl oppy port interface
•
Two COM ports •
PS/2 mouse and PS/2 keyboard ports•
Up to ten USB 2.0 (Universal Serial Bus) (4 Ports, 2 Front Headers, and 2 •
Type A Headers)
Super I/O: Winbond W83627HG
•
High Defi nition 7.1 Audio with Line-in, Line-out and Microphone•
Two TI 1394 ports•
Other
Wake-on-LAN (WOL)•
Console redirection•
Onboard Fan Speed Control by Thermal Management via BIOS•
CD/Diskette Utilities
BIOS fl ash upgrade utility and device drivers•
Dimensions
Ext. ATX 13.05" (L) x 12.075" (W) (331.47 mm x 306.71 mm)•
