ATF Installation Guide
PREPARATION
4
PARTS AND QUANTITIES
Many of the provided parts are pre-assembled before shipping. This helps to ensure all necessary parts are
included and checked for proper ȴt before delivery. Ensure all assembled parts are contained in the shipping
crate BEFORE starting installation. (See Figure 1.)
PART QUANTITY
Shade speciȴcation drawing ȃ speciȴc to your shade and provided as a separate
document
1
Mounting clamps w/mounting hardware and bolt covers 4
Pre-assembled actuators 2
Roller assembly w/mounting hardware 1
Outer crossbar w/mounting hardware 1
Mid-crossbar w/mounting hardware 1
Pre-rolled canvas (attached to roller assembly) 1
Pre-programmed electronic controller w/wireless remote 1
Starboard and port control harness w/Deutsch connectors 2
