ATF Silent Glide Boat Shade
INSTALLATION INSTRUCTIONS
SURESHADE
PO Box 51294
Philadelphia, PA 19115
Tel: 1-877-333-8323
International: 215-673-2307
www.sureshade.com
SURESHADE
®
TECHNICAL DOCUMENTATION

Table of Contents

Questions and Answers

  • J
    Jason HernandezAug 3, 2025
    How to troubleshoot SureShade ATF-SG Indoor Furnishing when it does not extend or retract?
    • K
      Kimberly PriceAug 3, 2025
      If your SureShade Indoor Furnishing shade isn't moving when you press the switch, the issue could stem from a few sources. First, ensure your boat's batteries are fully charged. Use a multimeter to check the current to the control box. Also, inspect the 5-amp fuse to see if it's blown and examine the wiring for any loose connections, making sure you're using the correct gauge wire.
  • M
    Matthew BrownAug 14, 2025
    Why is there a voltage drop when extending or retracting my SureShade Indoor Furnishing?
    • J
      Jesus DuncanAug 14, 2025
      A voltage drop while extending or retracting your SureShade Indoor Furnishing shade can be caused by a few things. Make sure your boat battery is fully charged. Also, confirm that you are using the correct gauge wire as specified by ABYC E-11, and check all wiring connections to ensure they are tight.
  • T
    Tiffany DiazAug 22, 2025
    What to do if the canvas is sagging when retracting my SureShade ATF-SG Indoor Furnishing?
    • W
      William GregoryAug 22, 2025
      If the canvas on your SureShade Indoor Furnishing is sagging when retracting, it likely needs more tension on the roller spring. To fix this, unzip the canvas from the outer crossbar and rotate the canvas to increase the tension. See Pre-Loading the Canvas on page 30.

Summary

General Information

SureShade Limited Product Warranty Statement

Outlines the terms and conditions of the SureShade product warranty.

SureShade ATF-SG Silent Glide Shade

Installation

Determining the Centerline of the Hardtop to Position the Shade

Setting the Mounting Clamps

Guides on how to disassemble and place the mounting clamps.

Installing and Securing the Actuators

Instructions for placing and securing the actuators to the mounting clamps.

Securing the Roller Assembly

Securing the Crossbars

Pre-loading the Canvas

Wiring the Electrical System

Provides instructions for connecting the shade's electrical components.

Initiating the SureShade ATF-SG Intelligent Control Box (ICB)

Details the setup sequence for the Intelligent Control Box.

Initiating the Remote Key Fob

Explains how to pair the remote key fob with the control system.

Troubleshooting

Troubleshooting Chart

A chart listing common problems, causes, and corrective actions.

Troubleshooting the SureShade ATF-SG Intelligent Control Box (ICB)

Specific troubleshooting steps for the ICB unit.

Force Hard Home Reset

SureShade ATF-SG Specifications
