10 Sensor signal outputs
10.3 Modbus output
Mode : RTU TCP
Baud rate : 19200
N/A
Device address :
Last digits of serial
number
Framing /
parity / stop bit
: 8, N, 1
Response time : 1 second
Response delay : 0 ms
Inter-frame
spacing
: 7 char
DHCP :
N/A
Yes
MAC : Set ex-factory
IP address : Dynamic or Static
Subnet : User configuration
Gateway : User configuration
Remark: Modbus communication settings can be changed usingS4C-FS
service App or the optional sensor display.
Holding register table (Modbus/RTU and Modbus/TCP)
Channel description Resolution Format Length
Modbus
register
address
Flow 0.1 FLOAT 4-Byte 6
Consumption 1 UNIT32 4-Byte 8
Reverse consumption 1 UNIT32 4-Byte 14
Flow Direction Indication* 1 UNIT32 4-Byte 42
* Value 0 identifies the same direction and 1 identifies the reverse
direction.
