7. TECHNICAL DESCRIPTION
7.1. TECHNICAL SPECIFICATION
Dimensions and weight:
• Width: 48.9 mm [1.92 in]
• Height: 54.8 mm [2.16 in]
• Thickness: 15.8 mm [0.62 in]
• Weight: 50.3 g [1.78 oz]
Depth Gauge:
• Temperature compensated pressure sensor.
• Salt water calibrated, in fresh water the readings are about 3% smaller
(calibrated complying with prEN 13319).
• Maximum depth of operation: 80 m [262 ft] (complying with prEN
13319).
• Accuracy: ± 1% of full scale or better from 0 to 80 m [262 ft] at 20°C
[68°F] (complying with prEN 13319).
• Depth display range: 0 … 99.9 m [300 ft].
• Resolution: 0.1 m [1 ft].
Temperature display:
• Resolution: 1ºC [1.5ºF]
• Display range: - 20 ... +50ºC [- 4 ... +122ºF]
• Accuracy: ± 2ºC [± 3.6ºF] within 20 minutes of temperature change
