38
Also incorporated is a fail-safe provision that
allows the operation at a restricted speed even
under such a failure condition.
NOTE:
If equipped with Keyless Start System:
• This diagnostic code is designed to appear
while the Keyless Start System is in ON
state.
If not equipped with Keyless Start System and
equipped with multi-function gauge:
• This diagnostic code is designed to appear
while the ignition key is turned on.
• The buzzer sound with diagnostic system
activating will be canceled by pushing the
ignition key in.
If equipped with monitor-tachometer:
• The CHECK ENGINE lamp will light briefly
when the ignition key is turned to the “ON”
position.
• The failed system can be identified by the
mode of the red CHECK ENGINE lamp flash-
ing and buzzer sounding.
This diagnostic code is designed to appear
while the ignition key is turned on.
• The buzzer sound with diagnostic system
activating will be canceled by pushing the
ignition key in.
NOTICE
If the diagnostic system activates while you
are operating your outboard motor, there is an
abnormal condition in one of the sensor sig-
nals of the control system.
Consult your authorized Suzuki marine dealer
for repair of the control system.
OIL CHANGE REMINDER
SYSTEM
This system informs the operator of the time for
replacing engine oil on the basis of the mainte-
nance schedule.
The system is designed to register the total
operating hours of the outboard motor and
function its operation when the preprogrammed
hours have reached.
(Refer to the INSPECTION AND MAINTE-
NANCE section.)
FLOWCHART OF OIL CHANGE REMINDER
SYSTEM
*1: Lapse of initial 20 hour’s operation
*2: Lapse of 80 hour’s operation
*3: Lapse of 100 hour’s operation
*4: When performing cancellation before sys-
tem activation
Action
Starting operation
CancellationIndication
(*1) (*4)
CancellationIndication
CancellationIndication
CancellationIndication
Repeat
(*2) (*4)
(*3) (*4)
(*3) (*4)
