85
FUSE
1. If equipped with Keyless Start System:
Turn the Keyless Start System OFF.
If not equipped with Keyless Start System:
Turn the ignition key to the “off” position.
2. Remove the motor cover.
3. Remove the fuse box cover and pull off the
fuse.
NOTE:
Use the fuse puller at the back of fuse box
cover, when the fuse is pulled off and installed.
Fuse box cover
Fuse box cover
Fuse puller
4. Remove the sub battery cable fuse.
5. Inspect the fuse and replace with new fuse if
needed.
NOTE:
If a fuse is blown, try to determine the root
cause and correct it.
If the cause is not corrected, the fuse may be
blown again.
Sub battery
cable fuse case
Normal fuse
Main fuse (60 A)/
Load fuse (60 A)
Blown fuse
Normal fuse Blown fuse
To Next Page
