47
4. Remove the Sub battery cable fuse.
5. Inspect the fuse and replace with new fuse if
needed.
Sub battery
cable fuse case
Sub battery
cable fuse
Spare fuse
Normal fuse
Main fuse (60A)
Blown fuse
CAUTION
Always replace a blown fuse with a fuse
of the same type and rating. If the new
fuse blows in a short time, consult your
Suzuki dealer or a qualified mechanic
immediately.
Normal fuse
Sub fuse (30A)
Blown fuse
SPECIFICATIONS
Power rated in accordance with NMMA procedure.
Item DF250S
Engine Type 4 Stroke
Number of Cylinders 6
Bore and Stroke 98.0 × 89.0 mm
(3.86 × 3.50 in.)
Piston Displacement 4028 cm
3
(245.7 cu. in.)
Maximum output 184 kW (250PS)
Full Throttle Operating Range 5300 – 6300
r/min. (min
–1
)
Idle speed (in Neutral) 650 ± 50 r/min. (min
–1
)
Ignition System Full-transistor
Engine Lubrication Trochoid pump pressure lubrication
Engine Oil Capacity 8.0 L (8.5/7.0 US/Imp. qt.)
