4-18 FUEL SYSTEM
FUEL TANK
DISASSEMBLY/REASSEMBLY
When disassembling or reassembling the fuel tank, refer to the construction diagram below.
 Bolt (1)
Fuel plug (1)
! Fuel hose assembly (1)
" Socket (1)
# Socket (1)
$ Clip (4)
% Primer bulb
& Fuel tank assembly (1)
' Fuel connector plug (1)
 Outlet (1)
) Outlet filter (1)
* O-ring (1)
+ Fuel tank cap
, Fuel tank cap gasket
