Suzuki DF9,9 - Mid Unit Service

MID UNIT 7-1
7
MID UNIT
CONTENTS
ENGINE SIDE COVER ..................................................................................7- 2
REMOVAL ...............................................................................................7- 2
INSTALLATION.......................................................................................7- 3
TILLER HANDLE...........................................................................................7- 4
REMOVAL ...............................................................................................7- 4
INSTALLATION.......................................................................................7- 5
DISASSEMBLY/ASSEMBLY ..................................................................7- 6
DRIVESHAFT HOUSING AND OIL PAN ......................................................7- 7
REMOVAL ...............................................................................................7- 7
INSPECTION ...........................................................................................7- 9
REASSEMBLY ........................................................................................7-10
SWIVEL BRACKET, STEERING BRACKET, CLAMP BRACKET...............7-13
REMOVAL/DISASSEMBLY ....................................................................7-13
INSPECTION ...........................................................................................7-16
REASSEMBLY ........................................................................................7-17
