6-2 POWER UNIT
POWER UNIT
REMOVAL
1. Remove both side covers. (See page 7-2.)
2. Remove recoil starter. (See page 5-2.)
3. Disconnect water hose 1 from thermostat cover and oil pan.
Disconnect breather hose 2 from cylinder head cover and
silencer.
4. Remove silencer and carburetor assembly 3.
(See page 4-4.)
5. Remove fuel pump 4. (See page 4-15.)
Before removing power unit:
• Disconnect battery cable from battery.
• Drain engine oil.
To Next Page
