SYMBOL
Listed in the table below are the symbols indicating instructions and other important information necessary
for proper servicing. Please note the definition for each symbol. You will find these symbols used throughout
this manual. Refer back to this table if you are not sure of any symbol(s) meanings.
SYMBOL DEFINITION SYMBOL DEFINITION
Torque control required.
Data beside it indicates specified
torque.
Apply the THREAD LOCK “1342”.
Apply the oil. Use the engine oil unless
otherwise specified.
Apply the THREAD LOCK SUPER
“1333B”.
Apply the SUZUKI OUTBOARD
MOTOR GEAR OIL.
Measure in DC voltage range.
Apply the SUZUKI SUPER GREASE “A”. Measure in resistance range.
Apply the SUZUKI WATER RESISTANT
GREASE.
Measure in continuity test range.
Apply the SUZUKI BOND “1207B”. Use peak voltmeter “Stevens CD-77”.
Apply the SUZUKI SILICONE SEAL. Use special tool.
