Suzuki VZR1800 2007 User Manual

4-28 DRIVELINE/AXLE
• Apply SUZUKI BOND to the mating surface of final gear case.
& 99000-31140: SUZUKI BOND “1207B” or equivalent
• Install the stopper plate F to the final gear case.
$
NOTE:
Two kinds of plates are available to lock the stopper at the
proper position.
• Apply SUZUKI BOND to the mating surface of swingarm.
& 99000-31140: SUZUKI BOND “1207B” or equivalent
• Apply Lithium Base Molybdenum grease (NLGI#2) to the pro-
peller shaft spline.
FINAL GEAR CASE INSTALLATION
NOTE:
To install the final gear case easily, move the dust boot front and
the universal joint turn into the propeller shaft.
When installing the plate, fit the protrusion B of plate
to the one of the bearing stopper grooves.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
