2-32 PERIODIC MAINTENANCE
OIL PRESSURE CHECK
Check the engine oil pressure periodically. This will give a good indication of the condition of the moving
parts.
OIL PRESSURE SPECIFICATION
If the oil pressure is lower or higher than the specification, the following causes may be considered.
LOW OIL PRESSURE
* Clogged oil filter
* Oil leakage from the oil passage
* Damaged O-ring
* Defective oil pump
* Combination of the above items
HIGH OIL PRESSURE
* Engine oil viscosity is too high
* Clogged oil passage
* Combination of the above items
OIL PRESSURE TEST PROCEDURE
Start the engine and check if the oil pressure indicator light is
turned on. If the light stays on, check the oil pressure indicator
light circuit. If the circuit is OK, check the oil pressure in the fol-
lowing manner.
• Remove the boot 1 and oil pressure switch lead wire 2.
• Remove the oil pressure switch 3.
• Install the oil pressure gauge and adaptor into the oil gallery.
• Install the oil pressure switch 4 into the adaptor.
• Warm up the engine as follows:
Summer : 5 min at idle r/min
Winter : 8 min at idle r/min
• After warming up, increase the engine speed to 3 000 r/min
(observe the tachometer), and read the oil pressure gauge.
& 09915-74521: Oil pressure gauge hose
09915-17410: Oil pressure gauge attachment
09915-77331: Meter (for high pressure)
• Install the oil pressure switch. ($3-86)
• Check engine oil. ($2-17)
400 – 700 kPa (4.0 – 7.0 kgf/cm
2
, 57 – 100 psi) at 3 000 r/min, Oil temp. at 60 °C (140 °F)

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
