PERIODIC MAINTENANCE 2-7
EXHAUST CONTROL VALVE
• Remove the rubber cover 1.
Check the exhaust control valve actuator 2 for its movement
when the ignition switch is turned on. If the exhaust valve actua-
tor does not move, check exhaust valve actuator electrical circuit
and exhaust valve carbon sticking. Check the exhaust control
cable play. ($7-12)
• Remove the two bolts and cover.
• Check the lock nuts tightness. If the lock nuts are loose,
adjust the cable play and tighten the lock nuts.
NOTE:
Install the rubber cover 1 correctly after inspecting it.
Inspect initially at 1 000 km (600 miles, 2 months) and
every 12 000 km (7 500 miles, 24 months) thereafter.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
