Suzuki VZR1800 2007 User Manual

9-34 CHASSIS
REMOVAL
• Remove the brake caliper bracket mounting bolt 1.
• Remove the cotter pin 2. (For E-03, 28, 33)
• Hold the rear axle with the special tool and remove the axle
nut 3.
% 09944-28320: Hexagon socket
• Raise the rear wheel off the ground and support the motorcy-
cle with a jack or wooden block.
• Draw out the rear axle and coller 4.
• Remove the rear wheel.
$
DISASSEMBLY
• Flatten the lock washers.
• Remove the bolts, washers and plates.
• Remove the driven hub joint 1 with the special tool and
wooden block.
% 09913-50121: Oil seal remover
Do not operate the brake pedal while removing the cal-
iper.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
