5-14 FI SYSTEM DIAGNOSIS
FI SYSTEM WIRING DIAGRAM
B/W
B/G B/G
G/W
G/Bl
R
P/B
Y/W
G/B
P/B
B/Bl
Dg
B
B/Br
Y
B/R R/B
B/W
Lg
W/Y
Lbl
W/Bl
W/B
W/G
B/Y
Y/G
P
Bl
R/Y
G
B
Y
W/Bl
O/G
Y/B Y/R
Gr/B
Gr/W
R/Bl
G/R
M
Ch
G
W/B
B/Lg
P/W
B/W
EXCVA
Tip-over sensor (TOS) Intake air temperature sensor (IATS) Engine coolant temperature sensor (ECTS) Intake air pressure sensor (IAPS) Secondary throttle position sensor (STPS) Throttle position sensor (TPS) Crankshaft position sensor (CKPS)
#2 #1
Speedometer
Tachometer
Fan relay
Fuel pump
Fuel pump relay
Ignition coil
PAIR solenoid valve
Gear position switch
#1 #1 #2 #2
Cooling fan motor
Fuel injector
5 S L Q P 9 J A 8 U X
6xc
F h g W ] G k | j i w d s M b t B a E Z m Y l z { 2 I 1 H
D 0 4 3
#1 #2
Heated oxygen sensor (HO2S)
(Except for E03, 28, 33)
Idle speed control valve (ISCV)
Clutch lever position switch
Headlight
Headlight relay
Starter button
Neutral indicator light
Side-stand relay
Ignition switch
15 A 10 A 15 A 30 A 15 A
Starter motor
Starter relay
Battery
Side-stand switch
Engine stop
switch
Secondary throttle valve actuator (STVA)
M
R/G
(Except for E03, 28, 33)

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
