Suzuki VZR1800 2007 User Manual

PERIODIC MAINTENANCE 2-25
Rear brake
The extent of brake pad wear can be checked by observing the
grooved limit line

A on the pad. When the wear exceeds the
grooved limit line, replace the pads with the new ones.
(!9-63)
%
BRAKE PEDAL HEIGHT
• Loosen the lock nut

1.
• Turn the push rod

2 until the brake pedal height becomes 25
– 35 mm (1.0 – 1.4 in)

A below the top of the footrest.
• Tighten the lock nut

1 securely.
& Rear brake master cylinder rod lock nut:
18 N·m (1.8 kgf-m, 13.0 Ib-ft)
" Brake pedal height

A:
Standard: 25 – 35 mm (1.0 – 1.4 in)
BRAKE LIGHT SWITCH
• Adjust the rear brake light switch so that the brake light will
come on just before pressure is felt when the brake pedal is
depressed.
Replace the brake pads as a set, otherwise braking
performance will be adversely affected.

Suzuki VZR1800 2007 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, 54-degree V-twin
Transmission	5-speed
Front Tire	130/70R18M/C 63H
Overall Height	1185 mm
Seat Height	705 mm
Torque	160 Nm @ 3200 rpm
Ground Clearance	140mm
Overall Length	2485 mm (97.8 in)
Power	125 hp (93 kW) @ 6200 rpm
