11
SV106 user's manual
also possible to set the mode of this push-button such that in order to start or stop the
measurements the user has to press it simultaneously with the <Shift> push-button.
<ENTER>
This push-button enables the user to enter the selected position shown on the screen
Menu list or to confirm selected settings. Some additional functions of this push-button will
be described in the following chapters of this manual.
(<Menu>) This push-button (pressed together with <Shift>) enables the user to enter the main list
containing six sub-lists: Function, Measurement, Display, File, Instrument and
Auxiliary Setup. Each of the mentioned above menu lists consists of sub-lists, elements
and data windows. These main sub-lists will be described in detail in the following chapters
of the manual. Double pressing the <Menu> push-button enters a list containing the last
eight opened sub-lists. It often speeds up control of the instrument as the user has faster
access to the most frequently used sub-lists for easy navigation.
[<Save>] This push-button (pressed together with <Alt>) enables the user to save measurement
results as a file in the instrument’s internal memory or on the SD-card.
<ESC>
This push-button closes the control lists, sub-lists or windows. It acts in an opposite
manner to the <ENTER> push-button. When the window is closed after pressing the
<ESC> push-button, any changes made in it are ignored in almost all cases.
([Cal.]) This push-button (pressed together with <Shift>) opens the Calibration sub-list.
[<S/P>]
This push-button enables the user to jump to pause or break the measurement process
temporarily. If there is no current running measurement in progress this push-button opens
the Setup Manager menu
<
3
>, <
4
>
These push-buttons enable the user specifically to:
• select the column in a multi column parameter list;
• select the parameter value in an active position (e.g. filter Z, A or C, Integration period:
1s, 2s, 3s, … etc.);
• control the cursor in Spectrum and Logger modes of result’s presentation;
• select the position of the character in the text editing mode;
• activate markers 2 and 3
• speed up changing the numerical values of the parameters when pressed and held.
(<
3
>, <
4
>) The <
3
>, <
4
> push-buttons pressed in conjunction (or in sequence) with <Shift> enable
the user specifically to:
• speed up changing the numerical values of the parameters (i.e. the step is increased
from 1 to 10 in the setting of Start Delay - path: Menu / Measurement / General
Settings / Start Delay);
• jump to the last or first character of an edited text line in the text edition modes,
