Section III: Operation
3.0.OPE.SL-160
CHANGING HOOK HEIGHT: 36” TO 54” JIB HEIGHT ADJUSTMENT PROCEDURE
STEP 4. CONTINUE TO TILT TELESCOPIC ARM REARWARD UNTIL THE DUMP CYLINDERS ARE FULLY EXTENDED.
REPLACE LOCK PIN AND SECURE WITH HITCH PIN.
WARNING:
DO NOT REMOVE LOCK PIN ON THE ADJUSTABLE JIB WHILE JIB IS IN THE 36” HOOK POSITION AND
THE TELESCOPIC ARM IS TILTED REARWARD (AS SHOWN). POSSIBLE PROPERTY DAMAGE AND/OR
PERSONAL INJURY MAY RESULT.
