Swegon SAFEGARDSYSTEMS FD 25 User Manual

FIRE DAMPER - FD
18
FD40
Rigid wall
REMOTE FROM WALL
(Promat)
≥ 110 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200kg/m³)
EI 60 (ve i↔o)S
300Pa
Rigid wall
REMOTE FROM WALL
(Isover)
≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200kg/m³)
EI 60 (ve i↔o)S
300Pa
Flexible wall
Plasterboard
type F (EN520)
FD40
Rigid wall
Battery 2x2, 1x2, 2x1 ≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200 kg/m³)
EI 120 (ve i↔o)S
500Pa
Floor/ceiling
Battery 2x2 ≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200 kg/m³)
EI 120 (ve i↔o)S
500Pa
FIRE DAMPER - FD
Gypsum plaster, mortar sealing od
mortar and cover boards
Sealing with mineral wool and cover
boards
Sealing with mineral wool and
fireproof coating - FireBatt
Applique installation
MF1/MF2 installation
Remote from wall installation
Battery installation
Check for more information about certificate
installations in the declaration of performance:
INSTALLATION
Aerated concrete ( ≥ 550 kg/m
3
) or
reinforced concrete (≥ 2200 kg/m
3
)
wall, more than 100 mm thick
Gypsum blocks (≥ 995 kg/m³) wall,
more than 70 mm thick
Plasterboard wall, type F (EN520),
Plasterboard wall, type A (EN520),
more than 100 mm thick
Aerated concrete ( ≥ 550 kg/m³) or
reinforced concrete (≥ 2200 kg/m³)
ceiling / floor, more than 100 mm thick
Shaft wall, steel frame construction
