The drone mainly comprises of the following systems:
-Flight control system,
-Communication system,
-Positioning system,
-Power system including the battery, ESC, motors and propellers.
Drone Overview
The Splash Drone 3 utilizes a brand new flight control system, incorporating 3 of the best
flight modes.
This mode uses the GPS module to achieve accurate and stabilized hovering,
intelligent flight, intelligent return and other intelligent flight mode functions.
It enables a maximum flight speed of 10m/s, maximum ascend speed of
4m/s, and maximum descend speed of 3m/s.
Specially designed for smooth aerial filming. The turning function of left
joystick is disabled, and is mixed into the right joystick, thereby freeing up
your left hand, with the other hand to used control the drone’s direction, and
flight path.
This mode does not use the GPS positioning function, but still maintains
attitude stabilization.
Note: With a good GPS signal, intelligent return can be achieved. A maximum
flight attitude angle of 25 degrees, a maximum flight speed of 16m/s, a
maximum ascent rate of 4m/s, and the maximum descend rate of 3m/s.
Please Note: In ATTI mode, and the drone’s speed is faster. When flying in a calm
environment, the pilot should allow a minimum of 30 meters for braking distance to
ensure flight safety.
Select the preferred flight mode of the drone using the remote mode switch on the
controller.
Flight Modes
GPS mode:
Smart Cruise:
ATTI mode:
Both in the ATTI or GPS mode, it is recommended to take off after the GPS signal is up to
or more than 9 stars, so as to ensure that the drone accurately records the return point.
When the Auto-Return function is activated, the drone can accurately return to the
take-off point.
