Remote Control LED Indicators
Working
Indicator
Power Status
Indicator
Warning Tone
RED Light ON
RED Light
slow flash
Yes
Yes
Light Stays ON
Remote Control battery low
Remote Control battery is
dangerously low
Status is good
Light Stays ONSlow Flash
Fast Flash
Remote controller and drone
receiver disconnected
PairingSuccess tone
When the remote control battery power is seriously insufficient, the remote control
power indicator light will slowly flash a red light whilst sounding a warning tone. If this
occurs, please land the drone as soon as possible, power off the drone, then Please
charge or replace the remote battery as soon as possible.
Conversion of the remote control throttleposition
The Remote control’s default joystick configuration is the American/European - Left handed
throttle, it can however, be set to the Japanese configuration, which is right hand joystick is
the throttle/yaw control.
Remote Control Joystick conversion method :
1.Using both index fingers, hold both joysticks in the upper right position at 45 degrees.
2. Now, using both thumbs, simultaneously press the power buttons to start the controller.
3. The left led will flash indicating the current joystick configuration setting.
4. Press the left pairing button and the left led will flash once for mode 1, flash 2 times for
mode 2, 3 times for mode 3 and 4 times for mode 4.
After the successful re-configuration of the right throttle setting, the right joystick is the
throttle and roll, the left joystick is the Yaw and pitch.
The left led will ash Joystick conguration
Mode1：Left hand throttle
Mode2：Not used
1 Green Flash
2 Green Flashes
Left pairing button
Left led
