©2018 SwellPro All Rights Reserved
35
3. In the horizontal plane, rotate the drone in a counter clockwise
rotation for 360 degrees.
4. Now, invert the drone, and rotate the drone in a counter clockwise
rotation for 360 degrees.
5. Swing the drone vertically, nose up (12midday), and perform a
counter clockwise rotation for 360 degrees.
6. Whilst vertical, turn the drone so the nose is to the left (3 o’clock),
and perform a counter clockwise rotation for 360 degrees.
7. Whilst vertical, turn the drone such its nose is pointing down (6
o’clock), and perform a counter clockwise rotation for 360 degrees.
2. Mode 1 - Left hand throttle: Pull the left joystick to the lower left
corner (45 degrees), the right joystick to the upper left corner (45
degrees), maintain this gesture for 2 seconds. The light changes to a
fast blinking red-green-yellow , the drone has entered into the
compass calibration mode. We will now refer to the face of a clock for
positional reference -12 -3 -6 -9.
Mode 3 - Right hand throttle: Move the Left joystick to the top left
corner (45 °), and the right hand joystick to the lower left corner (45 °),
as shown in the diagram, maintain this gesture for 2 seconds, the
red-green-yellow light will flash verifying the compass calibration
mode and status.
Mode 3 - Right hand throttle
Mode 1 - Left hand throttle
