74
ELECTRICAL SYSTEMS
Fuse Rating Fuse
Colour
Description
Battery 1 40 Amps Orange Fuse remotely located near battery
Battery 2 40 Amps Orange Fuse remotely located near battery 2 (where fitted)
8.18 12 Volt DC Fuses
WARNING: When replacing fuses always replace a fuse with the correct value. NEVER replace
with a higher value / rating as this could damage the wiring harness. If a replacement fuse ‘blows’
do not keep replacing the fuse as you could damage the wiring harness. Please investigate the
fault and contact your dealer.
Fuse Rating Fuse Colour Description
1 25 Amps White Battery Charger
2 7.5 Amps Brown Fridge Controls / Alarm
3 10 Amps Red 12V & USB Sockets / TV Amp
4 10 Amps Red Extractor, Cooker hood, Heki powered skylight. Alde or Truma
Combi Heating (Not En-Route), Whale Water Heater
5 10 Amps Red Appliances, Cooker, Toilet, Whale Space Heater, Locker
Mount USB, Tank Valves
6 10 Amps Red Water Pumps / Tank Heaters
7 7.5 Amps Brown Main lighting (not including spotlights with USB), Rear
ambient lighting, Offside awning light
8 7.5 Amps Brown Entry lights, Front ambient lighting
9 10 Amps Red Alde or Truma En-Route Heating, Marker Lights, En-Route
lighting, 12V Sockets, WiFi & Satellite supply
10 10 Amps Red Awning Light (Doorside) / Electric Step
11 20 Amps Blue/Yellow Not used
12 15 Amps Blue Towing 12V
13 10 Amps Red Compressor fridge
The following table shows the fuse allocation for the 13 fuses fitted to the PSU. Please note that fuses
are dependant on PSU versions, so not all fuses may be present.
Note: Fuses (2-13) have a Red LED below them which provides indication that the fuse has blown.
The charger fuse has a green LED which Indicates that the charger is working.
