ELECTRICAL SYSTEMS
Outline Specification
Input 230V 230 Volts / 0 to 16 Amps + / - 10%
Output 230V
RCD protected, 2 x MCB outputs of 10A & 1 x MCB
output of 16A
Separate switched channels for heating system and
charger
Input 12V 2 x 20A battery inputs via 2 x 4-way connectors
Solar Input
1 x Dedicated solar panel input capable of supporting
10A of solar power input (typically 180 to 200W) via a
2-way connector
Check the solar panel
rating plate to ensure
the maximum current is
<= 10A
Output 12V
25A total output via multiple switched channels
protected by 13 fused outputs
Battery Charger
Input 220-240 Volts AC +/- 10%, Frequency 50 Hz +/-
6%, Current 3A max.
DC Output 13.6 to 14.4 Volts nominal, Current 25
Amps max (300 Watts).
Signal Input
4 x Fresh water level, 4 x Waste water level, 1 x
Engine running, plus multiple vehicle connections,
sensor inputs for temperature & humidity
Fresh water negative
sensed Waste water
negative sensed
Data In / Out
CANBUS Data communication and power to
Control Panel via 6 way connector CI-Bus Data
communication to CI-Bus enabled devices via
RJ11/12 connector
IP rating IP31
Operating
temperature
Ambient 0 to 35° Celsius Charger case temperature
with full load 65° C Max
Automatic shutdown
and restart if
overheated /overloaded
Dimensions
EC454PSU,
EC456PSU
Power Supply
Unit
Overall size (HxWxD) 180 x 305 x 135mm Clearances
75mm above, 50mm left & right
Weight 3.8 Kg
EC463 Control
Panel
Overall size (HxWxD) 87 x 250 x 15mm Cut-out size
(HxWa) 70 x 233mm
Fixing centres
130*75mm Weight
114 g
8.21 Technical Data
Equipment - EC454, EC456
