Swift S30 Series User Manual

4
S306 with Pillar Transmitted Light Stand
S306S with Slim Pillar Transmitted Light Stand
(1) Eyepiece
(2) Diopter adjustment
(3) 360° Rotatable Binocular head
(4) 2X/4X objectives turret
(5) Fastening knob
(6) Focusing knob
(7) Incident light
(8) Power switch
(9) Stage clips
(10) Stage plate
(11) Pillar transmitted light stand
1
2
3
6
4
10
9
11
8
7
5
(1) Eyepiece
(2) Diopter adjustment
(3) 360
°
Rotatable Binocular head
(4) 2X/4X objectives turret
(5) Focusing knob
(6) Incident light
(7) Power switch
(8) Stage clips
(9) Stage plate
(10) Dimming handwheel
(11) Slim pillar transmitted light
stand
1
2
3
5
4
8
9
6
7
10
11

Swift S30 Series Specifications

General

Brand	Swift
Model	S30 Series
Category	Microscope
Language	English
