Fitted Equipment
125
PULLMAN BUNKS
1. Release catches, one at a time.
2. Release press studs on the bed board.
3. Grasp the bunk as shown and pull
carefully in direction of arrows.
4. The bunk is designed to automatically
move into the correct position.
5. Where a bed board is fitted, unfold and
make sure it is secured by press studs
when lifted into position. (The bed board
is required to protect both the occupant
and the window from damage during use
of the bunk.)
6. Locate safety boards.
7. Arrange seat cushions as appropriate.
BUNKS ARE DESIGNED TO CARRY A
CHILD TO A MAXIMUM OF 70KG
(11 STONE)
WARNING: Use upper bunks for sleeping
only, with the provided protection
against fall out in position
WARNING: Care shall be taken against
the risk of fall out when the upper bunks
are in used by children especially under
6 years of age, these bunks are not
suitable for use by infants without
supervision.
