Services
31
To fill the internal tank with solenoid valve
fitted
Ensure the taps are closed and that the
external pump is connected and suspended
in the water container with water present.
Also check that the tank drain valve is in the
closed position, and that the Ultrastore or
Alde drain valve is in the closed position as
detailed above.
With the pump selector switch in either
position, switch the solenoid / tank fill switch
to ‘ON’, and water will flow into the tank until
either the external water container is empty,
or the internal tank overflows. Progress can
be monitored using the water level gauge on
the control panel.
TRUMA WATERLINE
The Waterline allows mains water to be
connected to the caravan to supply water to
the taps and shower or internal tank.
WARNING: It is not recommended to
tow with water in the onboard water
tank as this could affect stability.
WARNING: Do not under any
circumstances connect your caravan to
the mains water supply without the
pressure reducer fitted. Damage will
occur to the caravan's water system.
1. Fig. A: Connect the fitted Crystal 2 plug
into the water inlet socket.
2. Uncoil the hose and screw cap adaptor
to the drinking water stand pipe. Plug in
the hose adaptor.
3. Turn on the mains water supply and
check for leaks.
Tank isolation and tank filling operations
with Waterline
The manual tank isolation valve,
(see pictures below).
Valve open – With all taps closed, and drain
valve at tank and Ultrastore closed as
detailed earlier in text, water at reduced
pressure from the waterline will flow into the
internal tank. This will continue until the tank
overflows via the fitted overflow pipe.
Progress can be monitored on the water
level gauge on the control panel. The pump
selector switch on the control panel can be
in either position. Valve closed – Check that
the drain valve at the Ultrastore is closed.
Select the central off position of the pump
selector switch on the control panel. Water
from the Waterline will only flow when the
taps are opened, and will not flow into the
internal tank.
Tank isolation and tank filling operations
with Waterline, with Solenoid valve fitted.
Tank fill / solenoid switch in ‘ON’ position -
With all taps closed, and drain valve at tank
and Ultrastore or Alde boiler closed as
detailed earlier, water at reduced pressure
from the waterline will flow into the internal
tank. This will continue until the tank
overflows via the fitted overflow pipe.
Progress can be monitored with the water
level gauge on the control panel. The
position of the pump selector switch on the
control panel is not important during this
operation.
Tank fill / solenoid switch in ‘OFF’ position -
check that the drain valve at the Ultrastore
or Alde boiler is closed as detailed earlier.
Select internal pump with the pump selector
switch on the control panel. Water from the
Waterline will only flow when the taps are
opened, and will not flow into the internal
tank.
Fig. A Fig. B
OPEN CLOSED
