Fitted Equipment
137
DESCRIPTION OF CONTROLS
Selection of the operating mode
When turned on, the system always waits 2
minutes before starting the compressor and
sets to AUTOMATIC MODE.
To select one of the manual modes, proceed
as follows:
• hand-set the ventilation speed by pressing
the key and the + and - keys;
• Press the “ MODE & SET” key to scroll
through the possible settings (manual
fresh air, manual warm air, ventilation,
automatic), select the required mode while
holding the key pressed down for two
seconds until the selected mode is
confirmed by the system.
Alarm visualizations
• When the display shows E1 and E2, the
temperature probes are defective;
• When the display shows the ON symbol
and the timer symbol flashes, the system
is waiting that 2 minutes from the last
compressor stop elapse.
Mode Description Display visualisation
AUTOMATIC The +/- keys enables the user to change the
PRE-SET TEMPERATURE.
In this mode, the machine automatically controls
the compressor, the heater and the ventilation
speed by comparing the SET TEMPERATURE
with the internal temperature.
MANUAL The +/- keys enables the user to change the
FRESH AIR PRE-SET TEMPERATURE.
The +/- keys allows changing the
VENTILATION SPEED.
In this mode, the machine automatically controls
the compressor and compares the SET
TEMPERATURE with the internal temperature.
MANUAL The +/- keys enables the user to change the
WARM AIR PRE-SET TEMPERATURE.
The +/- keys allows changing the
VENTILATION SPEED.
In this mode, the machine automatically controls
the heater and compares the SET
TEMPERATURE with the internal temperature.
VENTILATION The +/- keys allows changing the
VENTILATION SPEED.
The system only operates the fan inside the
vehicle.
In this mode, compressor and heater do not run.
