Fitted Equipment
74
Symbol Function Description
Circulating Pump With this switch in the OFF POSITION the boiler will heat DOMESTIC HOT WATER ONLY.
On/Off
With this switch in the ON POSITION the boiler will heat DOMESTIC HOT WATER AND HEATING.
The circulation pump is then controlled by the Room Thermostat. The boiler then operates on Gas,
electric or both to maintain water temperature.
Gas Burner This LED indicates that the LPG Burner is ignited
Flame Indication
Fault Warning This LED indicates that the LPG Burner has not ignited. To Re-Set turn the Gas Burner Switch "Off",
wait for 30 seconds then Turn the Gas Burner Switch "On"
The Compact 3000 Boiler is fitted with 2 x
230 volt x 1kW Heating Elements. Each
element is controlled by a switch on the
Control Panel so it is possible to operate on
1kW or 2kW.
Note: Gas and Electrical power can be used
at the same time.
The TP5000 Programmable room thermostat
"Programme Mode" is factory pre set with a
programme which often suits most people.
Setting the Clock and Day
- Press PROG to begin programming
- Use + or - to adjust time
- Press PROG again
- Use + or - to adjust day
1=Monday 2 =Tuesday etc
At initial warm up use gas 6kW &
electric 2kW combined for extra heat
and hot water performance
Mon-Fri
Event Time Temp °C
1 08.00 20
2 08.30 15
3 11.30 20
4 13.30 15
5 16.30 21
6 22.30 15
