Rear of the control unit:
12. Connecng socket for the power plug of the plug-in power pack
13. Connecng socket for the plug of any of the three available applicators
14. Connecng socket for the plug of any of the three available applicators
15. Connecng socket for the plug of any of the three available applicators
16. Connecng socket for the plug of the iMORE-sensor (iMORE oponal)
17. Connecon socket for the headphones (iSLRS oponal)
18. Connecon socket for the goggles (iSLRS oponal)
12 13 14 15 16 17 18
