E
Ensure that lug on Hanger
Bracket is engaged in slot
in Suspension Ball.
Locate Suspension Ball in Hanger Bracket.
Position Fan Motor Assembly so that
Chassis arm with terminal block is facing
away from opening in Hanger Bracket.
Take care to keep Fan Motor Assembly level
during installation to avoid marking ceiling.
D
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: 1300 360 280BEFORE LEAVING THE WORK SITE
E
Installing Fan Motor Assembly into Hanger Bracket
11
