Ensure electrical connections are good, and
that terminal block screws are secure.
Make EARTH (Green/Yellow) connection from
Fan Motor Assembly to appropriate terminal
on Hanger Bracket.
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: 1300 360 280BEFORE LEAVING THE WORK SITE
A
Connecting Earth Wire from Fan Motor Assembly to Hanger Bracket
12
EARTH
(Green / Yellow)
A
