B
Make LIVE and NEUTRAL connections from Remote
Control Receiver to appropriate terminals on Hanger
Bracket using wires marked LIVE IN (Brown) and
NEUTRAL IN (Blue).
Ensure that electrical connections are
good, and terminal block screws are
secure.
LIVE
(Brown)
NEUTRAL
(Blue)
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: 1300 360 280BEFORE LEAVING THE WORK SITE
B
Connecting Live and Neutral Wires from Remote Control Receiver to Hanger Bracket
23
