A
Make LIVE and NEUTRAL connections from Remote
Control Receiver to appropriate terminals on Fan Motor
Chassis using wires marked L (Brown) and N (Blue).
Ensure that electrical connections are good, and
terminal block screws are secure.
Ensure Remote Control Receiver LIGHT Wire is well
secured and cannot touch any moving parts.
LIVE
(Brown)
NEUTRAL
(Blue)
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: 1300 360 280BEFORE LEAVING THE WORK SITE
A
Connecting Live and Neutral Wires from Remote Control Receiver to Fan Motor Assembly
24
