Closing Screw Covers
28
Close all three Screw
Covers.
Note: To remove Fan Motor Housing open Screw Covers using a flat bladed
screw driver as shown. Remove fixing screw from hole, loosen two bayonet
slot screws and remove Fan Motor Housing by rotating anticlockwise and
lowering.
A
IF THERE ARE ANY PROBLEMS DURING INSTALLATION OF THE FAN, THE INSTALLER MUST CONTACT THE
HUNTER PACIFIC INTERNATIONAL WARRANTY LINE . TEL: 1300 360 280BEFORE LEAVING THE WORK SITE
A
A
A
Fan Blade must be removed before Fan Motor Housing is removed.
