The «favourite» key gives direct access to a predened function, and can be
congured according to the needs of the user.
In order to assign a function to the «favourite» key, give a prolonged press on
and then select the required function :
Validation of selection: By a prolonged press on , or a press on or
Note : a function can also be assigned via RS232 using the command <FCT
+ Function No.> / example : Change of Unit = <FCT4>
7. Favourite key
10 dir
9 rES
8 toL
7 ModE
6 PrE
4 Unit
3 SEt
2 CLr
1 HoLd
0 dAtA
Data transmission
(default)
Hold display
Re-initialise Min-
Max-Delta
Zero reset
Diameter calibration
(min.-max. mode)
mm – IN
Recall Preset
Nor–Min–Max-Delta
Tol ON–Tol OFF
Measurement
sense, positive -
negative
Multiplier
Bluetooth
®
10 dir
9 rES
8 toL
7 ModE
6 PrE
4 Unit
3 SEt
2 CLr
1 HoLd
0 dAtA
11 Mul
12 bt
8. Adjustment of the measuring system
MODE
SET
Certain applications need to adjust the instrument to the MIN (or MAX) measured
value. In this case, proceed as follows :
8.1 Adjustment of the instrument
• Enter a Preset value corresponding to the actual size of the standard (see
chap. 3)
• Select the MIN mode (or MAX, depending on the application) (see chap. 4)
• Make a standard measurement (going through the turnaround point)
• Adjust the instrument by selecting the SEt mode and pressing on the button
(see chap. 3)
• The instrument is adjusted and ready to measure.
8.2 Measure
• Make the measurements. The digital display stores and displays the MIN
(or MAX) measured value.
• Before each new measurement, reset the measured value by a short press
on
SET
