5. Removal & Installation of Engine
5-5
Remove rear brake hose clamp and rear brake
caliper.
Remove the right rear cushion lower bolt (1 bolt).
Remove the rear fork bolts (2 bolts).
Remove the rear wheel axle nut (1 nut).
Remove the rear fork and rear axle collars.
Remove left rear cushion lower bolt (1 bolt).
To this chapter contents
2 bolts
Brake hose clamp
1 bolt
2 bolts
Rear axle nut
1 bolt
