16. REAR WHEEL/REAR BRAKE/REAR CUSHION
16-2
Operational Precaution
General
Please refer to the Maintenance Manual for tubeless tire in respect to the removal, repair and
installation of the tires.
Service data
Unit: mm
Item Standard Allowable Limit
Radial - 2.0 Run-out of rear rim
Axial - 2.0
Thickness of rear brake lining 4.0 2.0
Free length of rear shock absorber 238.6 233.6
Torque Value
Rear shaft nut 10.0-12.0 kgf-m Rear cushion bolt 2.4-3.0 kgf-m
Rear brake calliper bolt 2.9-3.5 kgf-m Exhaust pipe attaching nut 1.0~1.2 kgf-m
Rear cushion upper bolt 3.5-4.5 kgf-m Exhaust pipe attaching bolt 2.7-3.3 kgf-m
Trouble Diagnosis
Run-out of rear wheel
z
Deformed or bent wheel
hub.
z
Improper tires.
z
Loose wheel shaft.
Soft Shock Absorber
z
The spring is too weak.
Noisy Brake
z
Worn brake lining.
z
Offset brake disc.
z
Improper assembly of brake
caliper.
z
Brake disc or wheel
imbalance.
Poor Performance of Brake
z
Improperly adjusted brake.
z
Contaminated brake disc.
z
Worn brake lining.
z
Air inside brake fluid pipe.
z
Grease on brake disc.
z
The brake fluid piping is
clogged.
z
The brake fluid pipe is
deformed or bent.
z
Insufficient amount of brake
fluid in the reservoir.
