38
Coolant Level Inspection / Filling
This scooter is filled with high quality coolant that is designed for the cooling system in the factory. It
contains a 50% solution of ethylene glycol based antifreeze. Position the scooter on level ground and in an
upright position. The coolant inspection window A is located under the left floor panel. The coolant level
must be between the FULL a and LOW b marks. Top up the coolant carefully when the level is at the
LOW mark.
Pull up the tip of the left floor panel mat A to remove it.
Wrap a screwdriver that covered with a protective cloth, and insert into the hole to open the
maintenance cap A .
Open the reserve tank cap A to fill in coolant.
A
A
A
a
b
A
Reverse the above steps to restore.
