Fuse Inspection

Fuses are arranged in the fuse box located under the luggage box. To remove the luggage box, follow the

below steps:

 Turn ignition switch off and set the scooter upright.

 Open the seat (page 19) and remove the luggage box bolts ○A .

 Carefully pull up the luggage box and disconnect the luggage box light coupler ○A on the left side, then

remove the luggage box.

 Open the fuse box to check the fuses ○A .

 Reverse the above steps to restore.

If a fuse fails, inspect the electrical system to determine the cause, and replace it with a new fuse of proper

amperage or have the fuses replaced by an authorized SYM dealer. Do not replace it with any material other

than the specified fuse. Have the scooter checked by an authorized SYM dealer if the fuse fails repeatedly.

○A

○B

○A
