11. Crankshaft / Crankcase
11-6
Crankcase assembly
Install the crankshaft and balancer shaft to the left
crankcase.
The marks on the crankshaft and balancer shaft
must be aligned.
Assemble the right crankcase to the left
crankcase.
Tighten the bolts on the right crankcase.
Install the oil pump drive sprocket, driven sprocket
and drive chain.
To this chapter contents
Marks on the crankshaft and
balancer shaft

Sym MAXSYM 400i Specifications

General

Displacement	399 cc
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Transmission	CVT
Front Suspension	Telescopic fork
Seat Height	800 mm
Weight	215 kg
Tires Front	120/70-15
Tires Rear	160/60-14
Engine Type	Single-cylinder, 4-stroke
Front Brake	Disc
Rear Brake	Disc
Fuel Capacity	13 liters
Rear Suspension	Dual shock absorbers
