4. ENGINE REMOVAL
4-2
Engine removal
Remove the luggage box and body cover.
Remove right and left side cover.
Remove the spark plug cap from the spark plug
section.
Remove the fuel output tube from carburetor.
Remove the vacuum tubes from inlet pipe.
Remove thermo switch coupler.
Remove the oil control cable from oil pump.
Remove the oil tube from oil pump and then clip
the tube.
Vacuum tube
Fuel output tube
Spark plug cap
This chapter Contents
Oil tube Oil control cable
Thermo switch coupler
