DOC 6511_Release K
ATS-6511A/B/C Users Guide
27
significant software/firmware changes that necessitate this update be done by completely
replacing the flash card. Please refer to the software release notes to accomplish this update.
3.3.2.1 Flash Card Replacement
This requires removing the currently installed flash disk and installing a new one which has the
updated software. Power the system down, press and release the SD card located in the SD Card
slot on the front panel. Remove the current flash disk and replace it with the new flash. Once the
new flash is securely installed restore power to the unit.
Caution: The system network and user configuration settings are NOT saved and the system
will need to be completely set up with the network and system settings.
Figure 8 Front Panel Flash Card
3.3.2.2 Remote Software Update
The ATS-6511 software can be updated remotely over the network. Users can download the new
software image onto the flash and run the software_update command to load the new software
onto the flash. Once the software has successfully been updated the system will automatically
reboot. The system network and user configuration files will be saved and reloaded onto the new
software image and do not require any additional steps. To update the system with the new
software:
1. FTP into the system and log in (username: update, password: update).
2. Switch to binary transfer mode if needed, upload (put) the .iso file, and quit ftp.
localhost> ftp 192.168.1.254
Connected to 192.168.1.254.
220 tflex FTP server (Version 6.00LS) ready.
Name (192.168.1.254:localhost): ftp
331 Guest login ok, send your email address as password.
Password:
230 Guest login ok, access restrictions apply.
Remote system type is UNIX.
Using binary mode to transfer files.
ftp> binary Use this command to switch to binary if needed.
200 Type set to I.
ftp> > put tflex-5-1-0.iso
local: tflex-5-1-0.iso remote: tflex-5-1-0.iso
227 Entering Passive Mode (192,168,150,61,192,177)
150 Opening BINARY mode data connection for 'tflex-5-1-0.iso'.
226 Transfer complete.
18026496 bytes sent in 36.7 secs (491.34 Kbytes/sec)
