DOC 6511_Release K
ATS-6511A/B/C Users Guide
49
• Power Source has failed; ensure the power source is available and connected to
the rear panel of the unit.
Users can also check the current system using the status alarm and the status
health:power_supply commands to check the system status.
ATS-6511>status alarm
power_supply:2 -- AC/DC supply missing, or hardware error
ATS-6511>status health:power_supply
[1]
[active] false
[occurrences] 0
[2]
[active] true
[occurrences] 1
[set]
[what] AC/DC supply missing, or hardware error
[when] 2013-07-06-16:12:51.346
If the fault condition has cleared, users are able to check the events in the system using the status
health:power_supply commands to check on events that occurred earlier.
ATS-6511>status health:power_supply
[1]
[active] false
[occurrences] 0
[2]
[active] false
[cleared]
[what] No errors
[when] 2008-10-06-16:14:38.874
[occurrences] 1
[set]
[what] AC/DC supply missing, or hardware error
[when] 2013-07-06-16:12:51.346
6.2.2 Fiber Inputs
The system has two fiber inputs (A and B) and one of these will always be the master (primary)
input. The master input will always display a solid green indication on the front panel when the
reference signal from the ATS-6501 is being used to steer the internal clock and a solid red when
the signal is lost. The redundant input will flash green/red (on 1 second/off 3 seconds) when the
reference signal from the ATS-6501 is present. The redundant input will also be red when the
reference signal is lost.
Input A/B Indicator Description
Steady Green Fiber input has been selected as the master and reference signal is present
Flashing Green Redundant fiber input is available and the system mode is auto.
Steady Red Reference signal is not present or fiber setting is incorrect.
Flashing Red Redundant fiber input is available and the system mode is manual.
Table 6-1 Fiber Indicators
