1-7-4 T2127EA
4. Setting for CD-VOL, DVD-BRT
and DVD-SHARP Data Values
1. Enter the Service mode. (See page 1-7-1.)
2. CD-VOL Adjustment: Press [VOL o] button on
the service remote control unit once to show "CD
VOL" on the display.
DVD-BRT Adjustment: Press [VOL o] button on
the service remote control unit twice to show "DVD
BRT" on the display.
DVD-SHARP Adjustment: Press [VOL o] button
on the service remote control unit three times to
show "DVD SHP" on the display.
DVD-CONTRUST Adjustment: Press [VOL o]
button on the service remote control unit three
times to show "DVD CNT" on the display.
3. CD-VOL Adjustment: Select "7" by pressing [CH.
o / p] buttons on the service remote control.
DVD-BRT Adjustment: Select "0" by pressing
[CH. o / p] buttons on the service remote control.
DVD-SHARP Adjustment: Select "0" by pressing
[CH. o / p] buttons on the service remote control.
DVD-CONTRUST Adjustment: Select "5" by
pressing [CH. o / p] buttons on the service remote
control.
VOL button
CD-VOL Adjustment (Factory mode)
CH.
button
VOL
button
VOL button
VOL button
VOL button
CD VOL 0 CD VOL 1
button
CH.
DVD-BRT Adjustment
CH.
button
DVD BRT 0 DVD BRT 1
button
CH.
DVD-SHARP Adjustment
CH.
button
DVD SHP 0 DVD SHP 1
button
CH.
VOL button
DVD-CONTRUST Adjustment
CH.
button
DVD CNT 0 DVD CNT 1
button
CH.
DVD Key Transmission
DVD KEY
DVD Test
DVD TEST
Fig. 4
To Next Page
