Synapse SE72 - Mounting and Wiring Procedures

SYN-INT-E014
•exposeddirectlytothelightorheatoftheSun,alamp,are
placeoranyotherheatsource;
•closeorinfrontofanairoutlet;
•closetoconcealedductsorachimney;and
•ina location withpoor air ow(e.g. behind a door), orwith
frequentairdrafts(e.g.headofstairs).
Thermostat Mounting and Connection
1.
Cut off power supply on lead wires at the electrical
panel in order to avoid any risk of electric shock.
2.Ensurethattheairventsofthethermostatarecleanandclear
ofanyobstruction.
3.Usingascrewdriver,loosenthescrewretainingthemounting
baseandfrontpartofthethermostat.Removethefrontpart
ofthethermostatfromthemountingbasebytiltingitupward.
