1.0 Technical Specifications
1.1 Specifications
512K RAM, Battery backed.
Magnetic Stripe (track 1, 2, or 3) – Optional
Bar Code (0-of-9, 2-of-5, 128)
Proximity Reader (HID 26 Bit) – Optional
Display 2x16 LCD backlit Alphanumeric with Decimal point
Programming ASCII-based, Over Communication Port
Communications Standard: RS-232 Port - Bi-directional Local
Communications Standard: RS-485 Port
Optional: 10/100 Ethernet
Power Voltage: 110/230 Vac + 10%, 100mA
Environment Operating Temperature -20
o
-60
o
C
Humidity: up to 95% RH
1.2 Available Options
Ethernet Communications: With the optional internal Ethernet card, the terminal can be connected to any 10/100
Ethernet network.
Wi-Fi (Wireless) Communications: The SY-765's wireless card allows the 765 to communicate over a
standard 802.11b network. The wireless network must be configured with an IP address, gateway, subnet, and
WEP key (if available).
P.O.E. (Power over Ethernet: The SY-765 has the optional capability of drawing its power from the Ethernet
communications line. This eliminates the need for high voltage power at the terminal locations. Note: The
Ethernet Network must support POE communications.
External Readers: The SY-765 has two reader ports to connect external devices such as a Bar code Gun or
an Access Control Swipe Reader that could be mounted outside a door.
1.3 Features
The SY-765 is constructed of injection molded plastic, which, pound for pound is stronger than steel, yet
lightweight and attractive. The terminals have recessed membrane keypads, which create a watertight seal
against external elements.
